Standard Products List of Serial Port Screen |
|||||||||||||||||||
|
No. |
Serial No. |
Power Interface |
Size |
Resolution |
Touch Screen |
Protocol Interfaces |
TFT Size Range |
TFT Max. Resolution
|
CTP |
RTP |
RS232 Optional |
RS485 Optional |
RTC |
Audio |
Video |
Expanding Application |
Outer Shell |
Attached |
|
| 1 | SDM-L268035CN-A0-S |
Micro USB 5V
|
3.5” | 320*240 | CTP |
TTL |
1.7~3.5” |
480*320 |
√ |
√ |
√ |
√ |
X | X | X | X |
√ |
Document |
|
| 2 | SDM-L268035RN-A0-S |
DC 3.3V |
3.5” | 320*240 | RTP |
TTL |
1.7~3.5” |
480*320 |
√ |
√ |
√ |
√ |
X | X | X | X |
√ |
Document |
|
| 3 | SDM-L768070CN-A0-S |
DC 12V |
7” | 800*480 | CTP |
TTL |
4.3~7” |
1024*600 |
√ |
√ |
√ |
√ |
√ |
X | X | X |
√ |
Document |
|
| 4 | SDM-L768043CN-A0-S |
DC 5V |
4.3” | 480*272 | CTP |
TTL |
4.3~7” |
1024*600 |
√ |
√ |
√ |
√ |
√ |
X | X | X |
√ |
Document |
|
| 5 | SDM-L769070CN-A0-S |
DC 12V |
7” | 800*480 | CTP |
TTL |
4.3~7” |
1024*600 |
√ |
√ |
√ |
√ |
√ |
√ |
X |
√ |
√ |
Document |
|
| 6 | SDM-L769043CN-A0-S |
DC 5V |
4.3” | 480*272 | CTP |
TTL |
4.3~7” |
1024*600
|
√ |
√ |
√ |
√ |
√ |
√ |
X |
√ |
√ |
Document |
|
| 7 | SDM-L368070CN-A0-S | DC 12V | 7” | 800*480 | CTP |
TTL |
4.3~7” |
1024*600 |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
|
√ |
Document |
|
| 8 | SDM-L76A070CN-A0-S | DC12V or 5V | 7” | 800*480 | CTP |
TTL |
4.3~10.1” |
1280*1024 |
√ |
√ |
√ |
√ |
√ |
√ |
X |
√ |
√ |
Document |
|
| 9 | SDM-L76A043CN-A0-S | DC5V | 4.3” | 480*272 | CTP |
TTL |
4.3~10.1” |
1280*1024 |
√ |
√ |
√ |
√ |
√ |
√ |
X | X |
√ |
Document |
|
|
Standard Products List of AD Board |
|||||||||||||||||||
| No. | Serial No. | Power Interface |
Size |
Resolution |
Touch Screen |
Display Port |
TFT Size Range
|
TFT Max. Resolution
|
CTP | RTP |
Input Interface VGA |
Input Interface USB
|
Output Interface LVDS |
Output Interface RGB |
Output Interface EDP |
Power Supply | Outer Shell | Attached | |
| 1 |
ADB-D251043CN-A0-S |
Micro USB 5V |
4.3” |
480*272 | CTP | HDMI/LVDS | All size | 1920*1200 | √ | √ | √ | √ | √ | X | X | √ | √ |
Document |
|
| 2 |
ADB-D251050CN-A0-S |
DC 12V |
5” | 800 *480 | CTP | HDMI/LVDS |
All size |
1920*1200 | √ | √ | √ | √ | √ | X | X | √ | √ |
Document |
|
| 3 | ADB-D251070CN-A0-S |
Micro USB 5V |
7” | 1024*600 | CTP | HDMI/LVDS |
All size |
1920*1200 | √ | √ | √ | √ | √ | X | X | √ | √ |
Document |
|
| 4 | ADB-D266101CN-A0-S |
DC 12V |
10.1” | 1920*1080 | CTP | HDMI/LVDS |
All size |
1920*1200 | √ | √ | √ | √ | √ | √ | X | √ | √ |
Document |
|
| 5 | ADB-D251215CN-A0-S |
DC 12V |
21.5” | 1920*1080 | / |
HDMI/EDP |
All size |
1920*1200 | √ | √ | √ | √ | √ | X | X | √ | √ |
Document |
|
| 6 | ADB-D255156CN-A0-S |
DC 12V |
15.6” | 800*1280 | / |
HDMI/EDP |
All size |
1920*1200 | √ | √ | √ | √ | √ | X | √ | √ | √ |
Document |
|
1) Above products are AVD's standard products for promotion purpose, and specification can be changed without prior notice
2) No MOQ limited (if any modification required, will follow the MOQ rules)
3) If you have any request on it, please contact with your sales for further confirmation or e-mail to sales@av-display.com.cn
