Product Feature
Standard List
| Size | Serial No. | Resolution |
Outline
(W*H*D/mm)
|
A.A(W*H)
(mm)
|
Interface |
Viewing
Angle
|
TYP
Luminance
(cd/m2)
|
Operating Temp.
(℃)
|
| 2.4 QT | AVD-TT24QT-NN-001-C | 450*600 | 38.72*51.56*0.78 | 36.72*48.96 | MIPI/MCU/SPI | free | 800 | -20~+80 |
| 3.5 QV | T035QV0028NWC01 | 320*240 | 76.85*64.00*2.8 | 70.08*52.56 | LVDS | free | 1000 | -30~+80 |
| 3.5 HV | T035HV0050NWC01 | 320*480 | 54.46*82.94*4.15 | 48.96*73.44 | SPI/MCU/RGB | free | 1000 | -30~+85 |
| 3.5 HV | T035HV0040DNB01-IS | 320*480 | 54.46*82.94*4.1 | 48.96*73.44 | MIPI | free | 500 | -30~+85 |
| 4.3 WQ | AVD-TT43WQ-NW-221-S | 480*272 | 105.40*67.10*2.95 | 95.04*53.856 | RGB | free | 500 | -30~+85 |
| 5.0 WV | AVD-TT50WV-NW-196-S | 800*480 | 120.70*75.80*2.80 | 108.00*64.80 | RGB | free | 500 | -30~+85 |
| 21.5 | T215FH0003NNC01 | 1920*1080 | 495.60*292.20*8.04 | 476.64*268.11 | LVDS | free | 1000 | -20~+80 |
* Wide temperature display selectable based on customer demand;
* Support various bondings: Air bonding, OCA bonding, LOCA bonding;
* The list above only shows Partial Wide Temperature TFT modules. If the target product is not in this list, please contact us freely.
